Level Measurement Bench

Teaching Objectives

Level Measurement Bench

Study of the sensors installation
Study of the different cases of applications.
Calibration of the sensors.
Determination of the characteristic curves of the sensors and their accuracy.

Working

The water network feed a vat through an adjustable pressure regulator (0 to 3 bar). The vat is equipped with a flow adjusting valve, an overflow, a total draining valve, a discharge valve with a leak flow adjusting valve and a steel rule to locate easely the level.
In the vat are installed several types of level measurement sensors: an ultrasonic sensor, a capacitive effect sensor, a float sensor and a hydrostatic pressure sensor.
The display of the different sensors is common and situated in the front side of the electrical cabinet. A 4 positions switch allows to select the sensor to study.
The device is mounted on a welded stainless steel frame, with PVC panel and is equipped with 4 adjustable feet.

Technical specifications

A regulator.
A membrane valve to adjust the feeding flow.
A vat in altuglas with support lid for the level sensors.
A capacitive effect level sensor.
An ultrasonic level sensor.
A level sensor by hydrostatic pressure measurement.
A float level sensor.
A digital indicator with graphic display by bar graph.
A valve adjusting the output flow.
An electrical cabinet.
Technical manual in English

Essential requirements

Power supply: 230 V, 50 Hz, 250 W
Water: network clean water 3 bar, 20 °C, 500 l/h.
Dimensions (L x w x h) : 850 x 450 x 1150 mm
