Analog and Digital Motor Control Teaching Set

Description:

D.C. Motor coupled with A.C. Alternator (Rotating arm type or Salient pole type)

Features: MG Set Lab Equipment

Larger size of bearings for longer life and trouble free operations.
Outer yoke made up of High permeability steel.
Ratings Available both in 1phase/3phase at 0.8 P.F.
Revolving Armature-Fixed Pole type or Salient pole Type.
Skewed Rotor construction with dynamically balance ensuring low noise.
Special guard also provided on the coupling to avoid any mishappening during operation.
Suitable copper conductor with best quality insulated material used to give continuous duty.
Vacuum pressure impregnation for armature and field windings ensuring high in sulation strength.
Voltage regulation within limit as per ISS.

This special type of D.C. Motor coupled with alternator non salient pole type can be used for following experiments:-

To determine the direct axis (Xd”) and quadrature axis reactance’s (Xq”) of an Alternator.
To determine the sub transient direct axis (Xd”) and quadrature axis reactance’s (Xq”) of Salient pole
To measure negative sequence & zero sequence reactance of Synchronous machines.
